Vertical-Fluted Anti-Fouling Film Fill

9621Counter Flow Cooling Tower Fill is a high-performance vertical-fluted film fill engineered for use in counter flow cooling towers operating under poor water quality conditions.

Send Inquiry

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

9621Vertical-Fluted Anti-Fouling Film Fill For Counter Flow Cooling Tower

9621Counter Flow Cooling Tower Fill is a high-performance vertical-fluted film fill engineered for use in counterflow cooling towers operating under poor water quality conditions. It is ideally suited for demanding industrial environments such as power plants, chemical processing facilities, oil refineries, mining operations, and food production. This fill media is designed to minimize fouling and deliver superior thermal performance even in systems with poor make-up water or process contamination.

To optimize performance, it is recommended to install a top layer of CF1900 fill, especially in the upper 12 inches (300 mm) of the fill pack. This area benefits from the cooling tower's natural spray wash effect, which helps maintain flow efficiency and reduces fouling risk.

Key Features

Vertical-fluted, anti-fouling design with engineered microstructure enhances water velocity, distribution, and thermal mixing.
Durable bonded edge construction with dedicated bond points for long service life.
Proprietary edge trim design effectively channels water to both sides of each sheet.
Manufactured from UV-stabilized PVC compounds that resist weathering, chemicals, fats, oils, and biological degradation.
Complies with Cooling Technology Institute (CTI) Standard 136 and offers excellent fire resistance due to its self-extinguishing properties.

Description

100% Raw Material

More than 7,000 tons PVC and PP resin in inventory, which can meet the production needs of customer orders in anytime and anywhere!

Special Wave design

Can supplied with PP & PVC material, specially designed for uncontaminated water sources.

Honeycomb

Good scale control

Low cycles of concentration

Minimal airborne dust

Easy Assembly

Use PVC glue can easily assemble into fill blocks, reduce the shipping cost.

Material Options

9621Counter Flow Cooling Tower Fill is available in standard thicknesses of 0.010″ (0.254 mm), 0.015″ (0.381 mm), or customized per project needs. All film fills are manufactured from high-quality, UV-stabilized PVC with excellent chemical and weather resistance. High-temperature PVC (HPVC) and ABS options are also available for specialized applications.
